BMGZ750.PNET – Calibratable electronics for belt scales with PROFINET IRT interface
- Heavy aluminium housing with resistant display and controls
- Graphical display, auto tare function, calibration via integrated calculation
- Integrated web browser
- Integrated PROFINET IRT interface
- Legal-for-trade version
The electronics of the BMGZ750-series has been designed for the demanding applications of stationary conveying systems. The illuminated, graphical display indicates the actual performance, daily amount, total amount and belt speed. Configurable analog and digital outputs are available to connect additional displays or controllers. All data is also provided via the integrated PROFINET IRT interface for easy system integration and data management. The factory-provided integrated web browser allows for quick configuration of the electronics via a regular laptop or pc and can even grant remote access to the system. The calibratable version allows you to invoice your customers according the precise measurement of the FMS belt scale. Operation and configuration via the free FMS BeltSCALE app is available as an option.
General technical details
| Anzahl Messrollen | 1 |
|---|---|
| Processor cycle time | 1 ms |
| Voltage output | 0 to 10 VDC, min. 1000 Ω (12 bit) |
| Current output | 0/4 to 20 mA, max. 500 Ω (12 bit) |
| Digital inputs | start tare procedure, production batch active, speed probe |
| Digital outputs | Tare function complete, 24 VDC, max. 100 mA |
| Power supply | 24 VDC (18 to 36 VDC) |
| Temperature range | -10 to 40 °C (14 to 104 F) |
| Functions |
|
Available variants
| Bild | Name | Protection class | Housing | CAD data | Watchlist |
|---|---|---|---|---|---|
| BMGZ750.W.PNET | IP 65 | wall mount | PDF DWG | ||
 | BMGZ750.S.PNET | IP 20 | panel mount | PDF DWG | |
 | BMGZ750.K.PNET | IP 65 | cabinet | PDF DWG |
Your benefits
- Robust design, IP65
- Intuitive operation and configuration, best visiblility
- Simple configuration
- Simple system integration
- Basis for direct billing to customers
Features
- Heavy aluminium housing with resistant display and controls
- Graphical display, auto tare function, calibration via integrated calculation
- Integrated web browser
- Integrated PROFINET IRT interface
- Legal-for-trade version
Industry
Construction and recycling, Construction mateterial recycling, Tunneling, Concrete plant, Mobile crusher, Mobile sieving plants, Gravel plant
